PowMr 5000W Hybrid Inverter, Off Grid All in one Inverter 48V DC to 110V AC, 5KW Pure Sine Wave Inverter Charger with 80A MPPT Controller, Max. 500V PV Input, for Lead-Acid and Lithium Batteries : Everything Else

Description

PV Priority :It will make full use of the solar input during the day in order to charge the battery bank.This effectively allows using the unit off-grid during peak utility times in order to cut costs on utility charging.Only when solar fails to start or is interrupted will the unit automatically switch to utility mode for backup. Utility Priority :In Utility Priority mode, the detected AC input will be priority for battery charging. If the power becomes unstable or unusable, then it will switch to PV charging. Hybrid Charging: PV and Utility will work together to charge the battery bank at the same time. Priority will be given to PV and utilize MPPT charging. Upon PV charging being insufficient, the power supply replenishes with Utility power. suitable for unstable areas of the grid Only Solar Charging:most energy-efficient way to charge your battery bank and does not make use of AC input. Utility will not charge the battery, even if it is available. Waveform Pure Sine Wave Rated input Voltage 110/120Vac Input voltage range(90Vac~140Vac) ±2% Frequency 50Hz/ 60Hz (auto detect) Overload / Short circuit Protection Breaker Efficiency >95% Max Bypass Current load 63A Rated Output (VA)5000(4100/4300/4500) Rated Output (W) 5000(4100/4300/4500) Output AC Voltage 120Vac(100/105/110Vac Settable) Unstable Input Error ±5% Output Frequency (Hz) 50Hz ±0.3Hz 60Hz ±0.3Hz Peak power 7000VA Rated Battery Voltage 48V (minimum start-up voltage 44V) Battery voltage range 40.0Vdc~60Vdc ± 0.6Vdc Power Saving Mode Self-Consumption ≤50W Battery type Lead Acid or Lithium Maximum Charging Current (AC) 40A Unstable Condition Error ± 5Adc;Charging Voltage Range 40 –60Vdc Short-circuit protection: Breakers and blown fuses ;Circuit Breaker Specifications 63A Overcharge Protection :Yes; Automatically alerts and then turns off charging after1 minute Solar (PV) Charging Recommended PV Max 500Vdc ;PV Operating Voltage 120-500Vdc MPPT Voltage Range 120-450Vdc;Battery Charging Range 40-60Vdc Maximum Input Power 5000W;Maximum Input Current 80A Maximum Output Power 5000W ;PV Charging Current Range 0-80A Short-circuit Protection Internal Fuse; Wiring Protection Reverse Polarity

Product Overview
