All-in-ONE Hybrid Solar Charger Inverter 48V 3500W Output 110Vac Off Grid Solar Inverter, 48V Inverter Built-in 80amp Mppt Controller Support Lead-Acid Lithium Battery Solar Power Utility Generator : Everything Else

Description

Battery type: 48V Lead Acid or Lithium Maximum Charging Current: 40A when Utility/Grid Charging, 0-80A when PV Charging. Charging Voltage Range: 40-60VDC Max Solar panel voltage accept: 145Vdc Solar(PV) Charing Operating Voltage range: 60-145Vdc (For PV to charge 48V battery banks, you will need a minimum PV Voc voltage of 61VDC) Solar(PV) MPPT Voltage Range: 60-115Vdc Maximum Solar(PV) Input Power: 4400W（please make sure solar panel never exceed this value） Max PV Input Current: 80A Maximum Solar(PV) output Power: 4200W(inverter will use Max 4200W to charge battery, but it is ok accept 4400W power from your solar panel.) Utility/Grid Rated input Voltage: 110/120Vac(90Vac~140Vac Input voltage range) ±2% Max Bypass Current load: 40A Inverter Output Waveform: Pure Sine Wave Inverter Rated Output (VA)(W): 3500W/VA Inverter Power factor: 1 Inverter Output AC Voltage: 120Vac Inverter Output Frequency (Hz) : 50Hz ±0.3Hz 60Hz ±0.3Hz Inverter Efficiency >91% Peak power:5000VA Motor Capability: 2HP
