60A Solar Charge Controller 12V/24V Automatic Voltage Recognition Solar Panel Charging Discharge Regulator with Dual 5V USB Output Backlight LCD Display : Patio, Lawn & Garden

Description

Automatic Identification System Voltage, 12V24V auto recognition.Humanized LCD displaying and double button operation of man-machine interface. High efficiency intelligent PWM 3 stage charging. The load control mode can be selected, the time function can be reset for street light at night. RS485 communication interface (optional) . Discharge capacity control and counter of ampere hour . Working Storage Function: record the total run time of system, record timers of error during running time, record times of full charged battery . Reliable over voltage protection, short circuit protection, over load protection, overcharge protection, over-discharge protection. Accurate temperature compensation, correcting the charging and discharging voltage automatically, improving the battery lifetime. Solar Panels, Battery, Solar Charge Controller positive poles are all connected together, adopting negative MOSFET in series control circuit. All terminals are in tight status after factory, in order to well connected, please loose all terminals at first. The following order of connection please do not free charge, or cause system voltage recognition fault. As figure, first connected the battery to controller correct poles. In order to avoid short circuit, please screw the cable of battery to the controller in advance, then connected to battery poles secondly. If your connection is correct, the LCD displaying will show battery voltage and other technical data. If LCD no indicate, please check the fault. The length of cable between battery and controller as shorter as possible. Suggest to 30CM - 100CM. As figure, connected solar panels with controller correctly. If the connection is successful and sunshine is full, the LCD will show solar panel and an arrow from solar panel to battery will be light. The voltage of solar panel is very high under sunshine, high voltage can cause injury or destroy controller. As figure, connected loads with controller correctly. Under 48V system, the reverse connection of solar panel will be destroy the solar charge controller. In order to avoiding injury from load voltage, please close to the output of controller with button at first, then connected the load on the controller. The controller do not offer reverse connection protection for load will be destroy bulb. To calculate the overall star rating and percentage breakdown by star, we don’t use a simple average. Instead, our system considers things like how recent a review is and if the reviewer bought the item on Amazon. It also analyzed reviews to verify trustworthiness.

Product Overview
