Chtaixi 12V-110V DC Miniature Circuit Breaker, 100 Amp 1 Pole Battery Breaker Protector for Solar PV System and RV, Thermal Magnetic Trip, DIN Rail Mount, High Current DC Disconnect Switch MCB 1P B100 : Automotive

Description

Fast, FREE Delivery is available to Prime members. To join, select "Try Amazon Prime and start saving today with Fast, FREE Delivery" below the Add to Cart button.Important:  Your credit card will NOT be charged when you start your free trial or if you cancel during the trial period. If you're happy with Amazon Prime, do nothing. At the end of the free trial, your membership will automatically upgrade to a monthly membership. Specifications Product name: DZ47NZ-125 Product type: DC Miniature Circuit Breaker Rated operational voltage: 12V - 110V DC Rated current [In]: 80A / 100 A / 125 A (optional) Poles: 1P / 2P (optional) Trip unit technology: Thermal-magnetic Curve code: B Breaking capacity: 6 kA Ics=Icu Uimp: 6 kV Mechanical durability: 10000 cycles Electrical durability: 4000 cycles Operating temperature: -13°F(-25℃) ~ 140°F(60℃) Mounting support: 35 mm DIN rail Tightening torque: 3.5 N.m Standard: IEC60947-2 Package includes 1 x DC miniature circuit breaker ( 1P NO DIN rail, 2P with 1 x DIN rail and 2 x screws ) Flame retardant material, sturdy and durable. Large space, put the wire end in the middle of the terminal hole. Reduce the wear of the contacts. Improve electrical durability. Install the 35mm DIN rail horizontally in a stable environment. Hang the circuit breaker slot on the DIN rail Push the lower end of the circuit breaker into the DIN rail Push the circuit breaker upward Turn the upper end of the circuit breaker out of the DIN rail To calculate the overall star rating and percentage breakdown by star, we don’t use a simple average. Instead, our system considers things like how recent a review is and if the reviewer bought the item on Amazon. It also analyzed reviews to verify trustworthiness.

Product Overview
