Nilight 50044R 5 Pack Waterproof 40/30 AMP Heavy Duty 12 AWG Tinned Copper Wires 5-PIN SPDT Bosch Style 12V Automotive Relay and Harness Set,2 Year Warranty : Automotive

Description

About Us With over 7 years of experience in the fuse and relay field, Nilight produces products that are long-lasting, powerful, and simple to use. Nilight produces quality products with cost-effective offers. With rich industry experience and advanced technology, Nilight combines industry-leading research and knowledge to build innovative fuses and relays that are at the forefront of design, intelligence, and power. The automotive relay is the ideal electrical relay to be used on off-road vehicles, boats, and dirt track cars that are often exposed to wet or muddy conditions. 12 AWG Wiring Harness for the main contact - pin 30, pin 87, pin 87a40A/30A high switching capability12AWG  Pin 87a  Yellow12AWG  Pin 87  Blue12AWG  Pin 30  Red16AWG  Pin 85  Black16AWG  Pin 86  White Specifications: Coil Voltage: 12V DC Coil Current: 160 MA Switching Voltage: 14V DC Current Rating: - NO 40A 14V DC- NC 30A 14V DC Initial contact resistance (at 6VDC 1A): 50m ¸ Max. Initial insulation resistance: 100M ¸ Min. (DC500V)Initial dielectric strength: - Between open contacts: AC500V, 50/60 Hz 1Min. - Between coil and contact: AC500V, 50/60 Hz 1Min. Endurance (operations): - Mechanical (at 7, 200 ops. /h): 10, 000, 000- Electrical (at 600 ops. /h): 100, 000Package Content: 5 x 5-PIN SPDT Relay and harness Please Note: - Easy to mount Instructions were included - For your and others' safety, let professional technicians to install the equipment. Nilight 50044R 5 Pack Waterproof 40/30 AMP Heavy Duty 12 AWG Tinned Copper Wires 5-PIN SPDT Bosch Style 12V Automotive Relay and Harness Set,2 Year WarrantyFound a lower price? Let us know. Although we can't match every price reported, we'll use your feedback to ensure that our prices remain competitive. Store (Offline) Store name: City: State: Please select province Please select province Price: ($) Date of the price: 01 02 03 04 05 06 07 08 09 10 11 12 / 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 / Please sign in to provide feedback. Submit Feedback P.when("A", "a-modal", "ready").execute(function (A, modal) { var $ = A.$; var instance; var title = $("#modalHeader").val(); A.declarative("pricingFeedback-modal-button", "click", function (event) { if (!instance) { var options = { name: "pricingFeedback-modal-content", dataStrategy: "preload", }; instance = modal.create(event.$target, options); } instance.update({ "header": title, "width": "550" }).lock().show(); }); }); P.when('A', 'ready').execute(function (A) { var $ = A.$; var csrf = $("#aapiCsrfToken").val(); var productPrice = $("#priceValue").val(); var hostname = $("#absoluteUrlPrefix").val(); var customerId = $("#customerId").val(); var isCustomerRecognized = ($("#isCustomerLoggedIn").val() === 'true'); var isCurrentGlOnlineOnly = ($("#isCurrentGlOnlineOnly").val() === 'true'); var asin = $("#asin").val(); var marketplaceId = $("#marketplaceId").val(); var country = $("#countryCode").val(); var offlineStoresList = $("#offlineStoresList").val(); var statesList = $("#statesList").val(); var errorMessages = { errorNoRetailerType: $("#errorNoType").val(), errorBadPrice: $("#errorBadPrice").val(), errorBadPriceShipping: $("#errorBadPriceShipping").val(), errorInvalidUrl: $("#errorInvalidUrl").val(), errorSubmission: $("#errorSubmission").val(), errorEmptyFields: $("#errorEmptyFields").val(), thankFeedback: $("#thankFeedback").val() }; var feedbackFormContent = document.querySelector('#feedbackForm'); var signUpContainer = document.querySelector('#signUpForm'); var feedbackFormFinalStateContainer = document.querySelector('#feedbackFormFinalState'); var states = JSON.parse(statesList); var offlineStores = JSON.parse(offlineStoresList); var offlineStoresEnabled = !isCurrentGlOnlineOnly; var currentDate = getCurrentDay(); var currentMonth = getCurrentMonth(); var currentYear = getCurrentYear(); if (isCustomerRecognized) { feedbackFormContent.style['display'] = 'block'; feedbackFormFinalStateContainer.style['display'] = 'block'; signUpContainer.style['display'] = 'none'; var enableOnlineStoreRadio = document.querySelector('#pricingFeedback_onlineRadio'); var enableOfflineStoreRadio = document.querySelector('#pricingFeedback_offlineRadio'); var onlineStoreInputForm = document.querySelector('#pricingFeedback_onlineInput'); var offlineStoreInputForm = document.querySelector('#pricingFeedback_offlineInput'); var offlineStateSelect = document.querySelector('#offlineState'); var offlineStoreSelect = document.querySelector('#offlineStoreNameList'); var submitButton = document.querySelector('#pricingFeedback_submit'); var onlineUrl = document.querySelector('#onlineUrl'); var onlinePriceRaw = document.querySelector('#onlinePriceRaw'); var onlineShippingRaw = document.querySelector('#onlineShippingRaw'); var onlineDay = document.querySelector('#onlineDay'); var onlineMonth = document.querySelector('#onlineMonth'); var onlineYear = document.querySelector('#onlineYear'); var onlineCalendar = document.querySelector('#onlineCalendar'); var offlineRadioContainer = document.querySelector('#offlineRadioContainer'); var offlineStoreName = document.querySelector('#offlineStoreName'); var offlineCity = document.querySelector('#offlineCity'); var offlineState = document.querySelector('#offlineState'); var offlinePriceRaw = document.querySelector('#offlinePriceRaw'); var offlineDay = document.querySelector('#offlineDay'); var offlineMonth = document.querySelector('#offlineMonth'); var offlineYear = document.querySelector('#offlineYear'); var offlineCalendar = document.querySelector('#offlineCalendar'); var thankYouDiv = document.querySelector('#pricingFeedback_thank'); var errorDiv = document.querySelector('#pricingFeedback_error'); var loadingGifDiv = document.querySelector('#loading'); setCalenderOrderBasedOnCountry(country); setInitialStates( onlineMonth, currentMonth, offlineMonth, onlineDay, currentDate, offlineDay, onlineYear, currentYear, offlineYear, onlineStoreInputForm, offlineStoreInputForm, enableOfflineStoreRadio, enableOnlineStoreRadio, onlineCalendar, offlineCalendar ); createPermalinkContainer(asin, hostname); for (let state of states) { var option = document.createElement('option'); option.setAttribute('value', state['value']); option.innerText = state['name']; offlineStateSelect.appendChild(option); } for (let store of offlineStores) { var option = document.createElement('option'); option.setAttribute('value', store); offlineStoreSelect.appendChild(option); } $("#pricingFeedback_onlineRadio").click(function () { onlineStoreInputForm.style['display'] = 'table'; offlineStoreInputForm.style['display'] = 'none'; }); $("#pricingFeedback_offlineRadio").click(function () { onlineStoreInputForm.style['display'] = 'none'; offlineStoreInputForm.style['display'] = 'table'; }); if (!offlineStoresEnabled) { offlineRadioContainer.style['display'] = 'none'; offlineStoreInputForm.style['display'] = 'none'; } $("#pricingFeedback_submit").click(function () { var feedbackSubmitted = submitFeedback( customerId, marketplaceId, asin, productPrice, onlineStoreInputForm, offlineStoreInputForm, onlineUrl.value, onlinePriceRaw.value, onlineShippingRaw.value, onlineDay.value, onlineMonth.value, offlineStoreName.value, offlineCity.value, offlineState.value, offlinePriceRaw.value, offlineDay.value, offlineMonth.value, thankYouDiv, errorDiv, submitButton, loadingGifDiv, errorMessages ); if (feedbackSubmitted !== null && !feedbackSubmitted) { errorDiv.innerHTML = getErrorDiv(errorMessages.errorSubmission); } }); A.on("a:popover:beforeHide:pricingFeedback-modal-content", function (data) { resetModalToInitialState(currentMonth, currentDate, currentYear); }); } else { feedbackFormContent.style['display'] = 'none'; feedbackFormFinalStateContainer.style['display'] = 'none'; signUpContainer.style['display'] = 'block'; var authPortalLink = getAuthenticationPageURL(asin, hostname); $("#signUpForm").one("click", function () { window.location = encodeURI(authPortalLink); }); } function setCalenderOrderBasedOnCountry(country) { var monthSections = document.getElementsByClassName('monthSection'); var daySections = document.getElementsByClassName('daySection'); var yearSections = document.getElementsByClassName('yearSection'); var firstDelimiters = document.getElementsByClassName('firstDelimiter'); var secondDelimiters = document.getElementsByClassName('secondDelimiter'); if (country === 'US') { for (let i = 0; i < 2; i++) { (monthSections[i]).style['order'] = '-1'; (firstDelimiters[i]).style['order'] = '0'; (daySections[i]).style['order'] = '1'; (secondDelimiters[i]).style['order'] = '2'; (yearSections[i]).style['order'] = '3'; } } else if (country === 'JP') { for (let i = 0; i < 2; i++) { (yearSections[i]).style['order'] = '-1'; (secondDelimiters[i]).style['order'] = '0'; (monthSections[i]).style['order'] = '1'; (firstDelimiters[i]).style['order'] = '2'; (daySections[i]).style['order'] = '3'; } } else { for (let i = 0; i < 2; i++) { (daySections[i]).style['order'] = '-1'; (firstDelimiters[i]).style['order'] = '0'; (monthSections[i]).style['order'] = '1'; (secondDelimiters[i]).style['order'] = '2'; (yearSections[i]).style['order'] = '3'; } } } function createPermalinkContainer(asin, hostname) { var permalinkHref = getPermalink(hostname, asin); var permalinkContainer = document.querySelector('#permalink'); var permalink = document.createElement('a'); permalink.setAttribute('href', permalinkHref); permalink.innerText = permalinkHref; permalinkContainer.append(permalink); } function getPermalink(server, asin) { return server + '/dp/' + asin; } function triggerPricingFeedback( customerId, marketplaceId, asin, price, retailerType, retailerUrl, retailerName, retailerCity, retailerState, retailerPrice, retailerShipping, sampleDate ) { var dataCart = { ourPrice: parseInt(price), retailer: { type: retailerType, name: retailerName, city: retailerCity, state: retailerState, price: parseInt(retailerPrice), shippingCost: parseInt(retailerShipping), url: retailerUrl }, date: sampleDate + "T00:00:00.102Z" }; return new Promise((resolve, reject) => { A.$.ajax($("#aapiEndpoint").val() + "/api/marketplaces/" + marketplaceId + "/products/" + asin + "/feedback/pricing", { type: 'POST', headers: { 'Accept-Language': 'en-US', 'Accept': 'application/vnd.com.amazon.api+json; type="product.feedback.pricing/v1"', 'Content-Type': 'application/vnd.com.amazon.api+json; type="product.feedback.pricing.request/v1"', 'x-api-csrf-token': csrf }, data: JSON.stringify(dataCart), xhrFields: { withCredentials: true }, success: function (responseContent) { $("#pricingFeedback_thankcontent").innerText = "Success! " + responseContent.toString(); resolve(); }, error: function (err) { $("#pricingFeedback_thankcontent").innerText = "Error! " + err.toString(); reject(); } }) }) } function getAuthenticationPageURL(asin, hostname) { return hostname + '/ap/signin?_encoding=UTF8&openid.assoc_handle=usflex&openid.claimed_id=http://specs.openid.net/auth/2.0/identifier_select&openid.identity=http://specs.openid.net/auth/2.0/identifier_select&openid.mode=checkid_setup&openid.ns=http://specs.openid.net/auth/2.0&openid.ns.pape=http://specs.openid.net/extensions/pape/1.0&openid.pape.max_auth_age=0&openid.return_to=https://www.amazon.com/dp//'; } function getCurrentDay() { var date = new Date(); return date.getDate().toString(); } function getCurrentMonth() { var date = new Date(); return (date.getMonth() + 1).toString(); } function getCurrentYear() { var date = new Date(); return date.getFullYear().toString(); } function setInitialStates(onlineMonth, currentMonth, offlineMonth, onlineDay, currentDate, offlineDay, onlineYear, currentYear, offlineYear, onlineStoreInputForm, offlineStoreInputForm, enableOfflineStoreRadio, enableOnlineStoreRadio, onlineCalendar, offlineCalendar) { onlineMonth.defaultValue = currentMonth; offlineMonth.defaultValue = currentMonth; onlineDay.defaultValue = currentDate; offlineDay.defaultValue = currentDate; onlineYear.defaultValue = currentYear; offlineYear.defaultValue = currentYear; var onlineMonthOption = document.querySelector('#onlineMonthOptionDefault'); onlineMonthOption.innerText = currentMonth; var onlineMonthPrompt = document.querySelector('#onlineMonthPrompt'); onlineMonthPrompt.innerText = currentMonth; var offlineMonthOption = document.querySelector('#offlineMonthOptionDefault'); offlineMonthOption.innerText = currentMonth; var offlineMonthPrompt = document.querySelector('#offlineMonthPrompt'); offlineMonthPrompt.innerText = currentMonth; var onlineDateOption = document.querySelector('#onlineDateOptionDefault'); onlineDateOption.innerText = currentDate; var onlineDayPrompt = document.querySelector('#onlineDatePrompt'); onlineDayPrompt.innerText = currentDate; var offlineDateOption = document.querySelector('#offlineDateOptionDefault'); offlineDateOption.innerText = currentDate; var offlineDayPrompt = document.querySelector('#offlineDatePrompt'); offlineDayPrompt.innerText = currentDate; var onlineYearOption = document.querySelector('#onlineYearOptionDefault'); onlineYearOption.setAttribute('href', currentYear); onlineYearOption.innerText = currentYear; var onlineYearPrompt = document.querySelector('#onlineYearPrompt'); onlineYearPrompt.innerText = currentYear; var offlineYearOption = document.querySelector('#offlineYearOptionDefault'); offlineYearOption.setAttribute('href', currentYear); offlineYearOption.innerText = currentYear; var offlineYearPrompt = document.querySelector('#offlineYearPrompt'); offlineYearPrompt.innerText = currentYear; if (onlineMonth.children && offlineMonth.children && onlineDay.children && offlineDay.children) { onlineMonth.children[currentMonth].setAttribute('selected', currentMonth); offlineMonth.children[currentMonth].setAttribute('selected', currentMonth); onlineDay.children[currentDate].setAttribute('selected', currentDate); offlineDay.children[currentDate].setAttribute('selected', currentDate); } onlineStoreInputForm.style['display'] = 'none'; offlineStoreInputForm.style['display'] = 'none'; enableOfflineStoreRadio.checked = false; enableOnlineStoreRadio.checked = false; if (onlineCalendar.style && offlineCalendar.style) { onlineCalendar.style['display'] = 'flex'; offlineCalendar.style['display'] = 'flex'; } } function submitFeedback( customerId, marketplaceId, asin, price, onlineStoreInputForm, offlineStoreInputForm, onlineUrl, onlinePriceRaw, onlineShippingRaw, onlineDay, onlineMonth, offlineStoreName, offlineCity, offlineState, offlinePriceRaw, offlineDay, offlineMonth, thankYouDiv, errorDiv, submitButton, loadingGifDiv, errorMessages ) { errorDiv.innerHTML = ''; let cleanRetailerType, cleanRetailerUrl, cleanRetailerName, cleanRetailerCity, cleanRetailerState, cleanRetailerPrice, cleanRetailerShipping, cleanSampleDate; var currentYear = getCurrentYear(); if (onlineStoreInputForm.style['display'] === 'table') { var onlineValidity = validateOnlineInputs(onlineUrl, onlinePriceRaw, onlineShippingRaw, errorMessages); if (onlineValidity.valid) { cleanRetailerType = 'ONLINE'; cleanRetailerUrl = truncate(trim(onlineUrl), 300); cleanRetailerPrice = trim(onlinePriceRaw); cleanRetailerShipping = trim(onlineShippingRaw); if (!cleanRetailerShipping) { cleanRetailerShipping = '0'; } cleanSampleDate = formatDate( currentYear, onlineDay ? onlineDay : getCurrentDay(), onlineMonth ? onlineMonth : getCurrentMonth() ); } else { if (onlineValidity.error) { errorDiv.innerHTML = getErrorDiv(onlineValidity.error); } return null; } } else if (offlineStoreInputForm.style['display'] === 'table') { var offlineValidity = validateOfflineInputs( offlineStoreName, offlineCity, offlineState, offlinePriceRaw, errorMessages ); if (offlineValidity.valid) { cleanRetailerType = 'OFFLINE'; cleanRetailerName = truncate(trim(offlineStoreName), 100); cleanRetailerCity = truncate(trim(offlineCity), 100); cleanRetailerState = truncate(trim(offlineState), 100); cleanRetailerPrice = trim(offlinePriceRaw); cleanRetailerShipping = '0'; cleanSampleDate = formatDate( currentYear, offlineDay ? offlineDay : getCurrentDay(), offlineMonth ? offlineMonth : getCurrentMonth() ); } else { if (offlineValidity.error) { errorDiv.innerHTML = getErrorDiv(offlineValidity.error); } return null; } } else { errorDiv.innerHTML = getErrorDiv(errorMessages.errorNoRetailerType); return null; } loadingGifDiv.innerHTML = getLoadingGifDiv(); if (price) price = parseFloat(price); return triggerPricingFeedback( customerId, marketplaceId, asin, price, cleanRetailerType, cleanRetailerUrl, cleanRetailerName, cleanRetailerCity, cleanRetailerState, parseFloat(cleanRetailerPrice), parseFloat(cleanRetailerShipping), cleanSampleDate ) .then(response => { errorDiv.innerHTML = ''; thankYouDiv.innerHTML = getThankYouDiv(errorMessages.thankFeedback); submitButton.style.display = 'none'; return response; }) .catch(err => { errorDiv.innerHTML = getErrorDiv(errorMessages.errorSubmission); return null; }); } function validateOnlineInputs(url, onlinePrice, onlineShipping, errorMessages) { if (isEmptyValue(url) || isEmptyValue(onlinePrice)) { return { valid: false, error: errorMessages.errorEmptyFields }; } else if (!isValidUrl(url)) { return { valid: false, error: errorMessages.errorInvalidUrl }; } else if (!isNumericPrice(onlinePrice) || (!isEmptyValue(onlineShipping) && !isNumericPrice(onlineShipping))) { return { valid: false, error: errorMessages.errorBadPriceShipping }; } return { valid: true, error: null }; } function validateOfflineInputs(offlineStoreName, offlineCity, offlineState, offlinePrice, errorMessages) { if ( isEmptyValue(offlineStoreName) || isEmptyValue(offlineCity) || isEmptyValue(offlineState) || isEmptyValue(offlinePrice) ) { return { valid: false, error: errorMessages.errorEmptyFields }; } else if (!isNumericPrice(offlinePrice)) { return { valid: false, error: errorMessages.errorBadPrice }; } return { valid: true, error: null }; } function getErrorDiv(errorMsg) { return ( '\n' + ' ' + errorMsg + '\n' + ' ' ); } function getThankYouDiv(thankMsg) { return ( '' + '' + thankMsg + '\n' + '' ); } function getLoadingGifDiv() { return ''; } function isValidUrl(url) { if (!url) { return false; } var encodedUrl = encodeURI(url); return encodedUrl.match( /^(https?:\/\/)?(([a-z0-9-]|%[A-F0-9]{2})+\.)+(([a-z]|%[A-F0-9]{2})([a-z0-9]|%[A-F0-9]{2})*)(:[0-9]+)?(\/[a-z0-9;:,~!+#@&=%\/$\.?_-]+)?$/ ); } function isNumericPrice(price) { if (!price) { return false; } return price.match(/^([0-9]+\.?[0-9]*)$|^([0-9]*\.[0-9]+)$/); } function isEmptyValue(input) { return !input || input.length === 0 || input.match(/^\s*$/); } function truncate(input, length) { if (!input) { return ''; } else { return input.substr(0, length); } } function formatDate(year, date, month) { return year + '-' + month + '-' + date; } function trim(input) { if (!input) { return ''; } else { return input.trim(); } } function resetModalToInitialState(currentMonth, currentDate, currentYear) { var enableOnlineStoreRadio = document.querySelector('#pricingFeedback_onlineRadio'); var enableOfflineStoreRadio = document.querySelector('#pricingFeedback_offlineRadio'); var onlineStoreInputForm = document.querySelector('#pricingFeedback_onlineInput'); var offlineStoreInputForm = document.querySelector('#pricingFeedback_offlineInput'); var onlineUrl = document.querySelector('#onlineUrl'); var onlinePriceRaw = document.querySelector('#onlinePriceRaw'); var onlineShippingRaw = document.querySelector('#onlineShippingRaw'); var onlineDay = document.querySelector('#onlineDay'); var onlineMonth = document.querySelector('#onlineMonth'); var onlineYear = document.querySelector('#onlineYear'); var onlineCalendar = document.querySelector('#onlineCalendar'); var offlineStoreName = document.querySelector('#offlineStoreName'); var offlineCity = document.querySelector('#offlineCity'); var offlineState = document.querySelector('#offlineState'); var offlinePriceRaw = document.querySelector('#offlinePriceRaw'); var offlineDay = document.querySelector('#offlineDay'); var offlineMonth = document.querySelector('#offlineMonth'); var offlineYear = document.querySelector('#offlineYear'); var offlineCalendar = document.querySelector('#offlineCalendar'); var thankYouDiv = document.querySelector('#pricingFeedback_thank'); var errorDiv = document.querySelector('#pricingFeedback_error'); var submitButton = document.querySelector('#pricingFeedback_submit'); var loadingGifDiv = document.querySelector('#loading'); var stateDefaultOption = document.querySelector('#stateDefaultOption'); var stateDefaultPrompt = document.querySelector('#stateDefaultPrompt'); if (thankYouDiv) { thankYouDiv.innerHTML = ''; } if (errorDiv) { errorDiv.innerHTML = ''; } if (loadingGifDiv) { loadingGifDiv.innerHTML = ''; } if (submitButton) { submitButton.style.display = 'block'; } onlineUrl.value = ''; onlinePriceRaw.value = ''; onlineShippingRaw.value = ''; offlineStoreName.value = ''; offlineCity.value = ''; offlineState.value = ''; offlinePriceRaw.value = ''; stateDefaultOption.innerHTML = $("#selectProvince").val(); stateDefaultPrompt.innerHTML = $("#selectProvince").val(); setInitialStates( onlineMonth, currentMonth, offlineMonth, onlineDay, currentDate, offlineDay, onlineYear, currentYear, offlineYear, onlineStoreInputForm, offlineStoreInputForm, enableOfflineStoreRadio, enableOnlineStoreRadio, onlineCalendar, offlineCalendar ); } }); .postpurchase-included-components-list-item { text-align: left; word-wrap: break-word; } .postpurchase-included-components-list-group { margin: 0 0 1px 18px; } What's in the box 5 pack Waterproof Relay and Harness .ask-product-docs-expander-content { padding-left: 0; margin-top: 0; } {} Compare with similar items This item Nilight 50044R 5 Pack Waterproof 40/30 AMP Heavy Duty 12 AWG Tinned Copper Wires 5-PIN SPDT Bosch Style 12V Automotive Relay and Harness Set,2 Year Warranty Nilight 50003R Automotive Set 5-Pin 30/40A 12V SPDT with Interlocking Relay Socket and Wiring Harness-5 Pack, 2 Years Warranty MICTUNING 12V Fuse Relay Switch Harness Set - 30A ATO ATC Blade Fuse, 5 Pin SPST Automotive Electrical Relays with Heavy Duty 14 AWG Wires - 6 Pack GOOACC 6 Pack Automotive Relay Harness Set 5-Pin 30/40A 12V SPDT with Interlocking Relay Socket and Harnesses,2 Years Warranty MICTUNING 12V 5 Pin Waterproof Relay Harness Set - SPDT Bosch Style Automotive 40Amp 30 Amp Relay with Heavy Duty 16AWG 14AWG Pre-Wired Harness 5 Pack Add to Cart Add to Cart Add to Cart Add to Cart Add to Cart Customer Rating 4.6 out of 5 stars (512) 4.6 out of 5 stars (2568) 4.6 out of 5 stars (566) 4.7 out of 5 stars (1184) 4.6 out of 5 stars (115) Price $21.27$21.27 $13.50$13.50 $17.00$17.00 $14.99$14.99 $20.99$20.99 Shipping FREE Shipping on orders over $25.00 shipped by Amazon or get Fast, Free Shipping with Amazon Prime FREE Shipping on orders over $25.00 shipped by Amazon or get Fast, Free Shipping with Amazon Prime FREE Shipping on orders over $25.00 shipped by Amazon or get Fast, Free Shipping with Amazon Prime FREE Shipping on orders over $25.00 shipped by Amazon or get Fast, Free Shipping with Amazon Prime FREE Shipping on orders over $25.00 shipped by Amazon or get Fast, Free Shipping with Amazon Prime Sold By Amazon.com Amazon.com Amazon.com Volay MICTUNING® Direct Item Type Name Nilight 5 PACK Waterproof Relay and Harness 40/30 AMP Heavy Duty 12 AWG Tinned Copper Wires 5-PIN SPDT Bosch Style 12V Automotive Relay and Harness Set,2 Year Warranty Nilight Automotive Relay Harness Set 5-Pin 30/40A 12V SPDT with Interlocking Relay Socket and Wiring Harness - 5 Pack，2 Years Warranty MICTUNING 12V Fuse Relay Switch Harness Set - 30A ATO ATC Blade Fuse, 5 Pin SPST Automotive Electrical Relays with Heavy Duty 14 AWG Wires - 6 Pack GOOACC 6 Pack Automotive Relay Harness Set 5-Pin 30/40A 12V SPDT with Interlocking Relay Socket and Harnesses,2 years Warranty MICTUNING 12V 5 Pin Waterproof Relay Harness Set - SPDT Bosch Style Automotive 40Amp 30 Amp Relay with Heavy Duty 16AWG 14AWG Pre-wired Harness 5 pack Compare with similar items P.when('cf').execute(function() { ue.count('dp:widget:dpxSize:dpxBTFSize', 219);}); if(window.mix_csa){window.mix_csa('[cel_widget_id="multi-brand-detail-creative-desktop_DPSims_3"]', '#CardInstancemetzrumOr3Cj991XcORubA')('mark', 'bb')} if(window.uet){window.uet('bb','multi-brand-detail-creative-desktop_DPSims_3',{wb: 1})} ._bXVsd_mbc_NPwEm{width:100%}._bXVsd_enhancedMBC_1VrRv{padding:0 50px;position:relative}._bXVsd_enhancedMBC_1VrRv ._bXVsd_container_1fHzw{max-width:calc(50% - 16px);min-width:calc(50% - 16px)}._bXVsd_butNext_UFKIs,._bXVsd_butPrev_2IIF1{position:absolute;top:50%;-webkit-transform:translateY(-50%);-ms-transform:translateY(-50%);transform:translateY(-50%)}._bXVsd_butNext_UFKIs button,._bXVsd_butPrev_2IIF1 button{-webkit-box-align:center;-ms-flex-align:center;-webkit-box-pack:center;-ms-flex-pack:center;align-items:center;display:-webkit-box;display:-ms-flexbox;display:flex;justify-content:center}._bXVsd_butPrev_2IIF1{left:0}._bXVsd_butPrev_2IIF1 button{-webkit-transform:rotate(180deg);-ms-transform:rotate(180deg);transform:rotate(180deg)}._bXVsd_butNext_UFKIs{right:0}._bXVsd_carousel_vF0DS{overflow:hidden;padding-right:2px}._bXVsd_carousel_vF0DS,._bXVsd_track_3BGVA{display:-webkit-box;display:-ms-flexbox;display:flex;width:100%}._bXVsd_track_3BGVA{position:relative;-webkit-transition:-webkit-transform .3s;transition:-webkit-transform .3s;transition:transform .3s;transition:transform .3s,-webkit-transform .3s}._bXVsd_noCarousel_1JmgP{display:-webkit-box;display:-ms-flexbox;display:flex;overflow:hidden;padding-right:2px;width:100%}._bXVsd_container_1fHzw{border:1px solid #ccc;height:175px;max-width:472px;min-width:351px;width:100%}._bXVsd_container_1fHzw:not(:first-child){margin-left:24px}[dir=rtl] ._bXVsd_container_1fHzw:not(:first-child){margin-left:0;margin-right:24px}[dir=rtl] ._bXVsd_carousel_vF0DS{padding-left:2px;padding-right:0}[dir=rtl] ._bXVsd_butPrev_2IIF1{left:auto;right:0}[dir=rtl] ._bXVsd_butNext_UFKIs{left:0;right:auto}@media (max-width:1549px){._bXVsd_track_3BGVA[data-enhanced-mbc=false] ._bXVsd_container_1fHzw[data-index="2"]{display:none}}@media (min-width:1350px){._bXVsd_enhancedMBC_1VrRv ._bXVsd_container_1fHzw{max-width:calc(33.33% - 16px);min-width:calc(33.33% - 16px)}}._bXVsd_mainImage_3CC_i{position:relative}._bXVsd_mainImageLink_2jGRr{-webkit-box-align:center;-ms-flex-align:center;-webkit-box-pack:center;-ms-flex-pack:center;align-items:center;display:-webkit-box;display:-ms-flexbox;display:flex;height:175px;justify-content:center;padding:18px;position:relative;width:175px}._bXVsd_infoWrapper_12_Kx{padding:0 14px}._bXVsd_trueBrandLogo_26x3O{margin-bottom:10px;max-height:40px;max-width:80px} ._bXVsd_mainImage_37a0o{position:relative}._bXVsd_mainImageLink_ouJek{-webkit-box-align:center;-ms-flex-align:center;-webkit-box-pack:center;-ms-flex-pack:center;align-items:center;display:-webkit-box;display:-ms-flexbox;display:flex;height:175px;justify-content:center;padding:18px;position:relative;width:175px}._bXVsd_infoWrapper_2no8_{padding:0 14px}._bXVsd_trueBrandLogo_1dnhP{margin-bottom:10px;max-height:40px;max-width:80px}._bXVsd_dealBadgeContainer_C8w4G{left:0;position:absolute;top:0;z-index:5}._bXVsd_followTrueBrandContainer_3QznN{-webkit-box-pack:justify;-ms-flex-pack:justify;-webkit-box-align:center;-ms-flex-align:center;align-items:center;-ms-flex-wrap:wrap;flex-wrap:wrap;justify-content:space-between}._bXVsd_followButtonContainer_29m9V{-ms-flex-item-align:center;-webkit-box-flex:0;-ms-flex-positive:0;align-self:center;flex-grow:0;margin-bottom:10px;pointer-events:all} ._bXVsd_content_3Lyvz{height:100%;width:auto}._bXVsd_content_3Lyvz a{position:relative!important;top:0!important}._bXVsd_sponsored_27Faw{color:#555;display:inline-block;font:11px Amazon Ember Regular,Amazon Ember,Arial!important}._bXVsd_sponsored_27Faw._bXVsd_simulate_aoBIv:hover{color:#111;cursor:pointer;text-decoration:none}._bXVsd_icon_3l1pD{background:url(https://m.media-amazon.com/images/G/01/ad-feedback/info_icon_1Xsprite.png) 0 0 no-repeat scroll transparent;display:inline-block;height:12px;margin:1px 0;vertical-align:top;width:14px}._bXVsd_simulate_aoBIv:hover ._bXVsd_icon_3l1pD{background-position:0 -12px} ._bXVsd_image_1pfbQ{max-height:100%;max-width:100%}._bXVsd_center_2savA{left:50%;position:absolute;top:50%;-webkit-transform:translate(-50%,-50%);-ms-transform:translate(-50%,-50%);transform:translate(-50%,-50%)} ._bXVsd_link_gJc5l{color:inherit;pointer-events:auto;position:relative;text-decoration:none!important;z-index:5}._bXVsd_fullSize_1_hF0{display:block;height:100%;width:100%}._bXVsd_hidden_L-XDK,._bXVsd_hidden_L-XDK:focus{outline:none!important} ._bXVsd_link_36_Co{height:100%;left:0;position:absolute;top:0;width:100%;z-index:0}._bXVsd_noPointerEvents_2MRWt{pointer-events:none}._bXVsd_hidden_6g_6K,._bXVsd_hidden_6g_6K:focus{outline:none!important} ._bXVsd_tint_M0L-m{background:#879596;height:100%;left:0;opacity:.07;pointer-events:none;position:absolute;top:0;width:100%;z-index:6} ._bXVsd_hidden_1N3Jg,[data-id*=cta-hidden]{display:none} ._bXVsd_content_2rsXy{pointer-events:none;position:relative;z-index:0}._bXVsd_adLabelContainer_2DLr0{height:20px;position:relative}._bXVsd_adLabel_oyFBC{-webkit-box-align:center;-ms-flex-align:center;align-items:center;display:-webkit-inline-box;display:-ms-inline-flexbox;display:inline-flex;position:absolute;right:5px}[dir=rtl] ._bXVsd_adLabel_oyFBC{left:5px;right:auto} ._bXVsd_badge_2AhPZ{-webkit-box-align:center;-ms-flex-align:center;align-items:center;display:-webkit-inline-box;display:-ms-inline-flexbox;display:inline-flex;font-size:12px;height:24px;line-height:1;padding:0 8px}._bXVsd_badge_2AhPZ[data-platform=desktop]{height:26px}._bXVsd_bestDealBadge_2jpH9,._bXVsd_dealOfTheDayBadge_1gqjn,._bXVsd_lightningDealBadge_1xuQ-{background-color:#b12704;color:#fff}._bXVsd_blackFridayDealBadge_3eLcB,._bXVsd_cyberMondayDealBadge_1lhDV{background-color:#cc0c39;color:#fff}._bXVsd_blackFridayDealBadge_3eLcB[data-platform=mobile],._bXVsd_cyberMondayDealBadge_1lhDV[data-platform=mobile]{font-size:11px;font-weight:700}._bXVsd_primeDayDealBadge_2Eths,._bXVsd_primeEarlyAccessBadge_2b1yM{background-color:#91f6fe;color:#232f3e;padding:0 11px} ._bXVsd_block_1vI8-{display:-webkit-box;display:-ms-flexbox;display:flex}._bXVsd_inline_9N1iS{display:-webkit-inline-box;display:-ms-inline-flexbox;display:inline-flex}._bXVsd_hFull_2lnNw{height:100%}._bXVsd_wFull_3f8b2{width:100%}._bXVsd_wrap_17Nni{-ms-flex-wrap:wrap;flex-wrap:wrap}._bXVsd_col_358pf{-webkit-box-orient:vertical;-webkit-box-direction:normal;-ms-flex-direction:column;flex-direction:column}._bXVsd_row_3CEm0{-webkit-box-orient:horizontal;-webkit-box-direction:normal;-ms-flex-direction:row;flex-direction:row}._bXVsd_itemsStart_78ErH{-webkit-box-align:start;-ms-flex-align:start;align-items:flex-start}._bXVsd_itemsCenter_3flfN{-webkit-box-align:center;-ms-flex-align:center;align-items:center}._bXVsd_itemsBaseline_3lQs7{-webkit-box-align:baseline;-ms-flex-align:baseline;align-items:baseline}._bXVsd_itemsSpaceBetween_2d8Yn{-webkit-box-align:space-between;-ms-flex-align:space-between;align-items:space-between}._bXVsd_itemsEnd_baqbf{-webkit-box-align:end;-ms-flex-align:end;align-items:flex-end}._bXVsd_contentStart_mMBF5{-webkit-box-pack:start;-ms-flex-pack:start;justify-content:flex-start}._bXVsd_contentCenter_3BjNx{-webkit-box-pack:center;-ms-flex-pack:center;justify-content:center}._bXVsd_contentBaseline_3KLkK{-webkit-box-pack:baseline;-ms-flex-pack:baseline;justify-content:baseline}._bXVsd_contentSpaceBetween_2tuNA{-webkit-box-pack:justify;-ms-flex-pack:justify;justify-content:space-between}._bXVsd_contentEnd_3qmfH{-webkit-box-pack:end;-ms-flex-pack:end;justify-content:flex-end} ._bXVsd_overrideHover_1DwB9._bXVsd_white_1j3GP:hover,._bXVsd_white_1j3GP{color:#fff!important} ._bXVsd_truncate_11Epi{display:block!important}[dir=rtl] ._bXVsd_truncate_11Epi svg{-webkit-transform:scaleX(-1);-ms-transform:scaleX(-1);transform:scaleX(-1)} ._bXVsd_container_GMk6b{height:100%;position:relative}._bXVsd_dpNoOverflow_24rve{overflow:hidden}._bXVsd_cardBorderDesktop_3QeYH{border:1px solid #f5f5f5;border-radius:4px;padding:12px 10px 10px 12px}._bXVsd_cardBorderMobile_36JeN{border:1px solid #f5f5f5;border-radius:4px;padding:4px} #a-page ._bXVsd_adLabel_1D6-W{font-size:11px!important} ._bXVsd_pixel_W0EBh{position:absolute;visibility:hidden} ._bXVsd_debug_1Yzz4{display:none} ._bXVsd_pSmall_3aIxm{padding-left:8px;padding-right:8px} Brands in this category on AmazonSponsored (function (w, id) {if (w && id && Date) {w.sbxGwentClient = w.sbxGwentClient || {}; w.sbxGwentClient[id] = Date.now(); } })(window, 'VlmCrLdwOaUzapekFAX3xQ');Ulincos pushbutton switch and relayShop Ulincos(function (w, id) {if (w && id && Date) {w.sbxGwentClient = w.sbxGwentClient || {}; w.sbxGwentClient[id] = Date.now(); } })(window, 'TSeVxeo4p4wUsGM74wFxdw');Rocker SwitchShop Nilight(function (w, id) {if (w && id && Date) {w.sbxGwentClient = w.sbxGwentClient || {}; w.sbxGwentClient[id] = Date.now(); } })(window, 'uM05n6otCbcNTOwtemyaZQ');LED Flasher Relays for Automotive & MotorcycleShop MGI SpeedWare(function (w, id) {if (w && id && Date) {w.sbxGwentClient = w.sbxGwentClient || {}; w.sbxGwentClient[id] = Date.now(); } })(window, '0qon.gCzek8O0o57W1bfTw');APIELE Automotive RelayShop APIELEif(window.mix_csa){window.mix_csa('[cel_widget_id="multi-brand-detail-creative-desktop_DPSims_3"]', '#CardInstancemetzrumOr3Cj991XcORubA')('mark', 'be')} if(window.uet){window.uet('be','multi-brand-detail-creative-desktop_DPSims_3',{wb: 1})} if(window.mixTimeout){window.mixTimeout('multi-brand-detail-creative-desktop', 'CardInstancemetzrumOr3Cj991XcORubA', 90000)}; P.when('mix:@amzn/mix.client-runtime', 'mix:multi-brand-detail-creative-desktop__p8bwpxEa').execute(function (runtime, cardModule) {runtime.registerCardFactory('CardInstancemetzrumOr3Cj991XcORubA', cardModule).then(function(){if(window.mix_csa){window.mix_csa('[cel_widget_id="multi-brand-detail-creative-desktop_DPSims_3"]', '#CardInstancemetzrumOr3Cj991XcORubA')('mark', 'functional')}if(window.uex){window.uex('ld','multi-brand-detail-creative-desktop_DPSims_3',{wb: 1})}});}); P.load.js('https://images-na.ssl-images-amazon.com/images/I/31URwomK4LL.js?xcp'); (window.AmazonUIPageJS ? AmazonUIPageJS : P).load.js('https://images-na.ssl-images-amazon.com/images/I/31WkIngSZbL._RC|61Back6w7KL.js_.js?AUIClients/AskAuiAssets&v79A0nk7#536927-T1.536938-T1'); (function(f) {var _np=(window.P._namespace("AskAuiAssets"));if(_np.guardFatal){_np.guardFatal(f)(_np);}else{f(_np);}}(function(P) { if (typeof P !== 'undefined') { P.when('askBrowseWidgetContentAjax').execute(function(askBrowseWidgetContentAjax) { askBrowseWidgetContentAjax.startLazyLoading(); }); } })); Looking for specific info? See questions and answers (window.AmazonUIPageJS ? AmazonUIPageJS : P).load.js('https://images-na.ssl-images-amazon.com/images/I/41PgtBPkB8L._RC|01HLxsL-v8L.js,11KGVmb0nxL.js,41uK3DtcmfL.js,31CLeONH-lL.js_.js?AUIClients/DesktopMedleyFilteringMetaAsset&pjDgm75N#412745-T1.386124-T1'); Customer reviews4.6 out of 5 stars4.6 out of 5 512 global ratings 5 star 78% 4 star 14% 3 star 5% 2 star 1% 1 star 3% How customer reviews and ratings work Customer Reviews, including Product Star Ratings help customers to learn more about the product and decide whether it is the right product for them. To calculate the overall star rating and percentage breakdown by star, we don’t use a simple average. Instead, our system considers things like how recent a review is and if the reviewer bought the item on Amazon. It also analyzed reviews to verify trustworthiness.

Product Overview
