New 5HP Electric Motor for air Compressor 56 Frame 3440 RPM 5/8" Shaft 20.3 AMP 230 Volt - -

Description

Technical Info: Horsepower: 5 Amperage: 20.3 fl amps at 230v. Phase: One / Single Phase 2 pole Voltage: RPM: 3440 Torque: 7.50 lb.ft Base: Reinforced fixed base Frame: Nema 56 frame G56H Shaft Diameter: 5/8" Keyed shaft Shaft Length: 1.874" Rotation: Reversible CW or CCW Rotation Frequency: 60hz Service Factor: 1.15 @ 230v Enclosure: ODP Open Drip Proof (internally fan cooled) Construction: Rolled Steel Overload: Yes - Manual reset button Efficiency: (100%) 85.0 Weight: 50 lbs. Additional Product information: Capacitor start allows for high starting torque WARNING: This product can expose you to chemicals which is [are] known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Product Overview
