Nilight 50003R Automotive Set 5-Pin 30/40A 12V SPDT with Interlocking Relay Socket and Wiring Harness-5 Pack, 2 Years Warranty: Automotive

Description

We need more information to verify that this product fitsyour vehicle. Nilight 12V 5-Pin Relay with 5-Pin Harness Socket (30A NC/40A NO) A relay is an electrically operated switch which use a smaller current to control a larger current. Functions as automatic adjustment, safety protection and conversion circuit. Specification Contact Capacity Normal Switching Capacity (Resistance load) NO (Normal Open) 40A 14VDC NC (Normal Closed) 30A 14VDC Max. Switching Current 40A Max. Switching Voltage 30VDC Max. Switching Power 560W Performance Parameter Contact Material: Silver Alloy Contact Resistance: 50mΩ Max. Operate Time (at nominal volt.): 10 msec. Max. Release Time (at nominal volt.): 5 msec. Max. Insulation Resistance: 100MΩ Min. (DC500V) Initial Dielectric Strength: - Between open contacts: AC500V, 50/60 Hz 1Min. - Between coil and contact: AC500V, 50/60 Hz 1Min. Vibration Resistance: - Functional: 10 ~ 55Hz at double amplitude of 1. 5 mm - Destructive: 10 ~ 55Hz at double amplitude of 1. 5 mm Shock Resistance: - Functional: 20G Min. - Destructive: 100G Min. Endurance (operations) Mechanical (at 7, 200 ops. /h): 10, 000, 000 Electrical (at 600 ops. /h): 100, 000 Ambient Temperature: -40 degree Celsius ~ +125 Degree Celsius (no condensation) Application Pre-wired relay with harness socket, compatible with almost all kinds of automotive devices that use a 12V DC power source. Widely used for car lights, fog lamps, headlights, seat warming, windshield wiper, starter, fans, speakers, traction control systems, etc. View larger View larger View larger Premium contactor with Normally Open@40A/14V DC and Normally Close@30A/14V DC. Max. 40A contact switching capability of the copper coil. The wire of this harness is of high quality. Good electrical conductivity, high temperature and melting resistance and outstanding bending performance. Unique interlocking design provides simple and easy installation. The relay sockets come with color-labeled wires for accessories wiring, safe and convenient. The relay is compatible with almost all automobiles and devices equipped with a 12 V DC power supply. For all applications including rear window defroster, pump control, fog light, headlight, car air conditioner, cooling fan, and much more.
