2P 250V Low Voltage DC Miniature Circuit Breaker for PV System, Grid System, DIN Rail Mount, Breaker DC Circuit Amp Solar Double Pole(63A) -

Description

No featured offers availableWe feature offers with an Add to Cart button when an offer meets our high standards for: Quality Price, Reliable delivery option, and Seller who offers good customer service “No featured offers available” means no offers currently meet all of these expectations. Select See All Buying Options to shop available offers. Specifications: Item: Schneider Electric Model: C65H-DC 2P Standard: IEC60947-2/GB14048.2 Poles: 2P Rated Current: 16A/32A/63A(Optional) Rated Voltage: DC250V Ultimate Breaking Capacity(ICU): 10kA Trip Characteristics: B, C Breaking capacity: Icu=10kA Rated Impulse-withstand Voltage(Uimp): 5kV Current Limiting Class: 3 Interrupter ways: vacuum circuit breaker Mechanical Life: 20,000 times (IEC 60947-2/GB14048.2) Electrical Life: 10,000 times (IEC 60947-2/GB14048.2) Isolation: Yes, Effectively breaking the instructions on the handle in the open position Impulse withstand voltage: 5kV Operating Temperature: -25℃~+70℃ Storage Temperature: -40℃~+85℃ Heat & Humidity Resistance: 55℃, 95%RH Size: 8.2 x 3.6 x 7cm / 3.22 x 1.41 x 2.75" Application: Solar panel off grid system Solar panel on grid system Wind and solar hybrid system Any other DC system Short circuit protection Overload protection Control Isolation Connection Tunnel type terminal blocks Terminal connection area: 1~32A, the wires used in 25 2 and below 40~63A, the wires used in 35 2 and below Modular structure, can be easily installed on the guide rail DIN standard Bistable locking clip, the installation more convenient Current Level(A):1~25/ 32~63 Screw: M5/M6.5 Rated torque(Nm):2.5/3.5 Ultimate torque(Nm):5.1/5.6 National standards Rated torque (Nm):2/3.5 C65H-DC breaker B and C Type trip curve IEC 60947-2/GB 14048.2, 10kA WALFRONT's categories include industrial, auto parts, home furnishing, sports outdoor, digital, maternal and child pets, music, etc. Our products range from industrial maintenance, low and medium voltage equipment and instrumentation to electronic components. When did we start? Launched in 2017, WALFRONT quickly became a leading industrial brand we have served more than millions of tool shops and homes around the world, and have become one of the most popular online sellers for industrial and commercial supplies suppliers. 250 volts_of_direct_currentTo calculate the overall star rating and percentage breakdown by star, we don’t use a simple average. Instead, our system considers things like how recent a review is and if the reviewer bought the item on Amazon. It also analyzed reviews to verify trustworthiness.

Product Overview
