Rockville RXM8BTW 1500w Peak/750w Dyno-Certified RMS Marine 8 Channel Digital Class D Power Amplifier with Bluetooth Wireless Integration : Electronics

Description

Features: Rockville RXM8BTW 1500w Peak/750w Dyno-Certified RMS Marine 8 Channel Digital Class D Power Amplifier with Bluetooth Wireless Integration Compact design and extremely high power (Do not be fooled by the compact size; this amp is a beast!!!) Peak: (Use these ratings when comparing with the top budget brands such as Boss, Power Acoustik, etc) 1500 Watts System Power Bridged Power Output at 4 Ohms: 380 Watts x 4 Channels. Dyno Certified RMS Power Ratings: (Certified Dyno Test / Less than 1 % THD) (Use these ratings when comparing with top brands such as Kicker, Rockford Fosgate, etc) RMS Power Output at 4 Ohms: 65 Watts x 8 Channels RMS Power Output at 2 Ohms: 95 Watts x 8 Channels RMS Bridged Power Output at 4 Ohms: 190 Watts x 4 Channels Configurable to 8-6-4 channels or 4.2 System Bluetooth Wireless with Auto Pairing UV and Salt Water Resistant Paint, Silk Screen and Heat Sink Enclosure Marine-Grade Conformal Coated Boards Resist Corrosion from Salt Spray and Moisture LED Power and Protect Indicators TI Digital Class D Audio Topology High Speed MosFET Power Supply Studio Grade Bipolar Output Stage Transistors Micro Size Architecture with SMD Component Circuitry Compact Design and High Power Non-Corrosive High Gloss White Aluminum Casing Selectable Bass Non-Corrosive Brushed Aluminum Casing Conforms to the American Boat and Yacht Council (ABYC) Marine Electronic Standards Bass Equalization: Fully Adjustable 0 - 12dB at 45Hz 4-Way System Protection Circuitry (DC, Short, Thermal, Overload) Heavy-Duty Aluminum Alloy Heat-sink Stainless Steel RCA Level Inputs Stainless Steel Bolt Down Molded Terminals 4CH / 8CH Input Selector Mode Independent Crossover Controls between CH1-4 and CH5-8 Full Range / Low Pass / High Pass Configurable Variable High-Pass Filter: 50Hz - 250Hz at 12dB/per Octave Variable Low-Pass Filter: 50Hz - 250Hz at 12dB/per Octave Frequency Response: 10Hz - 40KHz S/N Ratio: >100dB Minimum THD: <0.05% Damping Factor: >200 at 100Hz Input Voltage: 150mV - 6V RCA Line Output 80A Fuse rating! Channel Seperation: >60dB Input Impedance: 22K Dimensions 6.7" W x 2" H x 11.5" L

Product Overview
